HP83640A HP 83640A儀器發生器
Agilent / HP 83640A 高頻信號發生器,頻率帶寬10 MHz to 40 GHz
HP 83640A高頻信號發生器調頻:AM, FM, Pu，最大調頻偏差:+/- 8 MHz!Agilent / HP 83640A提供優秀的諧波性能,至少50dB諧波下26.5GHz 2.0 ~承運人,至少40dB低于載體26.5GHz以上。HP83640A信號發生器提供優秀的諧波性能與諧波至少50分貝以下承運人從2.0 ~ 2650千兆赫,和至少40個分貝以下載體265千兆赫以上。
Agilent / HP 83640A選件說明:
·83640A 001增加步驟衰減器
·83640A 002內部調制發電機
HP83640A合成的清掃者是標準的卓越的程序需要高性能的準確性與綜合源和速度和多用途性掃描振子。合成的寬帶頻率范圍和精確的1赫茲的頻率分辨率(選擇)產生于密探008里的間接合成、使安捷倫HP83640A高頻信號發生器single-sideband達到低相位噪聲性能。
描述
The Agilent 83640A synthesized sweeper is the standard of excellence for applications requiring the high performance and accuracy of a synthesized source and the speed and versatility of a sweep oscillator. Synthesized broadband frequency coverage and precise 1 Hz frequency resolution (Opt 008) are generated by indirect synthesis, enabling the Agilent 83640A to achieve low single-sideband phase noise performance. It delivers excellent harmonic performance with harmonics at least 50 dB below the carrier from 2.0 to 26.5 GHz, and at least 40 dB below the carrier above 26.5 GHz.
Scan modulation to simulate antenna scan patterns
Accurate fixed and swept frequency offset for two-tone measurement
User flatness correction for leveling at remote points in the test system
General purpose source for use in component test, receiver test and for frequency conversion
Frequency range: 10 MHz to 40 GHz
Sweep modes: Step, List, Ramp
Maximum power: < 26.5 GHz: +10 dBm
Maximum power: > 26.5 GHz: +6.0 dBm
Power sweep range: -20 dBm to maximum power
Phase noise (38 GHz at 10 KHz): -70 dBc
Max FM deviation (locked): +/- 8 MHz
